1. The interior is filled with EVA material (ethylene vinyl acetate) which is a sponge-like material that is highly flexible and elastic.
2. The exterior is coated with reinforced fiber and polyurea, giving the produce outstanding shock resistance and wear resistance.
3. Offers outstanding resistance against splits and cracks caused by oysters and shells attached to quays, and there is no need for pressure control such as pneumatic stowing.

※EVA (Ethylene Vinyl Acetate)

EVA foam fenders with outstanding cost performance
IMC offers abundant variations of sizes and surface colors to satisfy our customers’ requests.

規格 (直径×長さ) Specifications (Dia × length)	圧縮60% / Compression deflection at 60%		参考重量 Reference Weight (kg)
規格 (直径×長さ) Specifications (Dia × length)	反力 Reference force (kN)	吸収エネルギー Energy absorption (kJ)	参考重量 Reference Weight (kg)
500 × 1000L	71	8	34
600 × 1000L	86	12	45
700 × 1500L	161	27	101
1000 × 1500L	205	49	206
1000 × 2000L	274	64	275
1200 × 2000L	337	93	405
1200 × 2400L	390	110	475
1350 × 2500L	463	145	626
1500 × 3000L	624	216	927
1700 × 3000L	696	273	1191
2000 × 3500L	990	456	1923
2000 × 4000L	1110	505	2298
2200 × 4500L	1396	679	2992
2500 × 4000L	1386	781	3434
2500 × 5000L	1750	985	4272
3000 × 5000L	2050	1410	6411
3000 × 6000L	2460	1695	7293
3300 × 6500L	2950	2245	8335
4500 × 9000L	19650	7860	21460

* We can provide quotes for sizes not included in the above table. Please feel free to contact us.

Achieving high energy absorption and low reaction force compared to conventional products with a commonly and broadly used type.
Performance can be adjusted by adjusting internal pressure.

規格 (直径×長さ) Nominal size Dia × length	Initial internal pressure	Guaranteed energy absorption	Reaction force at GEA defiection	Hull pressure (internal pressure) at GEA defiection
		GEA	R	P
		Minlmum value at deflection 60 ± 5%	Tolerance ±10%	Reference value
mm	kPa	kJ	kN	kPa
500 × 1000L	50	6	64	132
600 × 1000L	50	8	74	126
700 × 1500L	50	17	137	135
1000 × 1500L	50	32	182	122
1000 × 2000L	50	45	257	132
1200 × 2000L	50	63	297	126
1350 × 2500L	50	102	427	130
1500 × 3000L	50	153	579	132
1700 × 3000L	50	191	639	128
2000 × 3500L	50	308	875	128
2500 × 4000L	50	663	1381	137
2500 × 5500L	50	943	2019	148
3300 × 4500L	50	1175	1884	130
3300 × 6500L	50	1814	3015	146
3300 × 10600L	50	3067	5257	158
4500 × 9000L	50	4752	5747	146
4500 × 12000L	50	6473	7984	154

* We can provide quotes for sizes not included in the above table. Please feel free to contact us.

規格 (直径×長さ) Nominal size Dia × length	Initial internal pressure	Guaranteed energy absorption	Reaction force at GEA defiection	Hull pressure (internal pressure) at GEA defiection
		GEA	R	P
		Minlmum value at deflection 60 ± 5%	Tolerance ±10%	Reference value
mm	kPa	kJ	kN	kPa
500 × 1000L	80	8	85	174
600 × 1000L	80	11	98	166
700 × 1500L	80	24	180	177
1000 × 1500L	80	45	239	160
1000 × 2000L	80	63	338	174
1200 × 2000L	80	88	390	166
1350 × 2500L	80	142	561	170
1500 × 3000L	80	214	761	174
1700 × 3000L	80	267	840	168
2000 × 3500L	80	430	1150	168
2500 × 4000L	80	925	1815	180
2500 × 5500L	80	1317	2653	195
3300 × 4500L	80	1640	2476	171
3300 × 6500L	80	2532	3961	191
3300 × 10600L	80	4281	6907	208
4500 × 9000L	80	6633	7551	192
4500 × 12000L	80	9037	10490	202

* We can provide quotes for sizes not included in the above table. Please feel free to contact us.
